TCMT 110204T IB55
Triangular positive inserts with a single CBN flat rake tip for machining hardened steel.
| Applicable Material | | Cast Iron | Hard Materials | | Fixing Hole Diameter (D1) | 2.85 mm |
| Application | | Ext. 60° Triangle 91° Approach | Ext. 60° Triangle Facing | Int. 60° Triangle 91° Approach | Int. 60° Triangle 95° Approach | | Tool Type | Turn Ultra hard Inserts |
| Insert Style | TCMT | Min D.O.C. | 0.05 mm |
| Corner Radius (RE) | 0.4 mm | Depth of Cut Maximum (APMX) | 0.5 mm |
| Insert Size | 2-1T | Min. Turning Feed (ft(min)) | 0.05 mm/rev |
| Cutting Edge Length (L) | 11 mm | Max. Turning Feed (ft(max)) | 0.15 mm/rev |
| Insert Thickness (S) | 2.38 mm | Clearance Angle Major (AN) | 7 Degrees |
| Inscribed Circle Diameter (IC) | 6.35 mm | Chip Breaker Type | W |
| Cutting Edge Material | PCBN | Measurement Type | Metric |
| Coating | Uncoated | Body Material | Carbide |
| Grade | IB55 | Unit | M |
Product Features
| Family Description | Triangular positive inserts with a single CBN flat rake tip for machining hardened steel. | FamilyName | TCMT (CBN) |
| Remarks | For dimensions and tolerances, see more info. | BrandName | Iscar |
| COO | Switzerland |
Shipping Info
Weight per item
0.0130
Name
Turning Indexable Inserts
FamilyName
TCMT (CBN)
BrandName
Iscar
